JEDEC/WAFFLE TRAYS

Antistat ensure all our waffle / IC trays are antistatic and are available for use as either IC shipping and/or IC baking trays.

All our shipping trays are built in compliance with JEDEC thick and thin standard dimensions. Mid temperature trays can be baked to 140°C while low temperature trays can withstand a maximum sustained temperature of 65°C. Trays are constructed in modified polysulfone (PS) or equivalent for mid-temperature applications and polycarbonate (PC) for low temperature applications because of their high deflection temperature, superior strength, and dimensional stability. All JEDEC waffle trays have the same “X” and “Y” dimensions and are easily stacked for storage and manufacturing.

Antistat are able to provide certain waffle trays from stock, however if you require trays for packaging more complex semiconductor devices than please contact us as we may be able to offer an alternative solution.

Heat resistance requirements should be specified at the point of order.

Antistat offers trays for the following package types:

BGA CABGA CBGA CFP
CQFP CSP DSBGA EPBGA
FBGA FCBGA FQFP LCC
LFBGA LFP LQFP MLF
PLCC PQFP QFP PGA
SSOP SVFP TBGA TQFP
TSOP TSOPII VFBGA SOIC
JEDEC Tray Lid and Foam - Antistat

Clear Universal Tray Cover & LD30SD Black Foam

This product contains both a tray cover and dissipative low density polyethylene foam. The static dissipative tray lid is designed for safe handling and transport of products. This product has maximum product protection and is exceptionally easy to use
