SMT Splice Tapes & Tools

Antistat has over 30 years of experience in manufacturing Leader Tape Extenders, SMT Feeders and SMT Carrier Tapes. Offering SMT Splice Tapes and Tools for all surface mount applications.

Antistat produces and distributes a wide range of production tools and consumables that are used in ESD splicing and jointing. These items include Shims, SMD Tapes & Extenders, Tape Connectors, Splice Tools and more!

Our Splicing Tools provide a quick and easy method of joining component reel tapes together. Suitable for both paper and plastic component tape, the splicing tool enables component tapes to be joined quickly and securely through the use of a brass shim.

For accurate alignment, the tapes are first arranged by means of the locating pins and locked into place. The shim is then riveted into the cut ends of the SMD tapes joining them securely. Finally, the cover tapes are joined by use of pre-cut adhesive tape connectors, available in different widths to suit different SMD tapes.

Check out the Splice Tape product range and see our handy video ‘Splicing Carrier Tape in 4 Easy Steps’ below. If you need further information or require a quote, please email us info—@antistat—.—co.uk

Splice Tape Connectors increase throughput and yields by approximately 15-20%, suitable for use on all major SMT pick and place feeders.

Splice Tape Extenders provide an additional 19″ of tape as a leader. This reduces wastage making it highly efficient.

Splice Carrier Tape with punched holes for use with all major SMT Pick and Place feeders. Available in various colours and sizes.

Double Splice Tape guarantees perfect and reliable joints in all kinds of paper carrier tape. Double Splice Tape provides precise joining.

SMT Manual Splice Tool for use with single splice shims and splice tape of any width for increased productivity.

Splice Tool for use with bandolier type shims for increased productivity. Stapler designed hand tool, durable and can be used for all SMT material.

Single Splice Shims used with tape splicing to join the end of old component reel to the beginning of a new reel.

Bandolier Type Shims designed to meet the standards of EIA-481B, suitable for use with all size carrier tapes.

Splice Tape with shims (combined). Can be used for all pick and place feeders. Increases throughput and yields by approximately 15%.

For further information on the Antistat range of SMT Shims, Tapes, Tools and Cover Tape Connectors – all of which can be supplied singularly in kit form or in bulk.

Or if you need any expert advice/help with knowledge on SMT Splice Tape and Tools, please contact us below, or ring 01473 836 200.
